MEAN WELL HDR-15-5 – Reliable 5V AC/DC Power Supply for DIN Rail

The MEAN WELL HDR-15-5 is a compact and efficient AC/DC power supply designed for DIN rail mounting (TS-35/7.5 or 15). With its slim profile (only 17.5 mm wide), it is ideal for installations with limited space. This model delivers a stable 5 V DC output at up to 2.4 A and 12 W total power.

It supports a wide AC input voltage range of 85–264 V (or 120–370 V DC), ensuring compatibility for both industrial and home automation systems. With an operating temperature range of -30 to +70 °C and insulation resistance of up to 3000 V, the HDR-15-5 offers robust performance even in harsh environments. With high efficiency (up to 80%) and protections against short circuit, overload, and overvoltage, it is an ideal choice for automation control, smart homes, distribution boards, and more.

Key features:

• 12 W output, 5 V / 2.4 A

• Ultra-slim design – only 17.5 mm wide

• DIN rail mountable (TS-35)

• Wide input range (AC & DC)

• Protections: short-circuit, overload, overvoltage

• High efficiency: up to 80%

• Operating temp: -30 to +70 °C

• Certifications: CE, UL, TUV

Applications: smart homes, industrial automation, lighting control, distribution panels, sensors, IoT devices, communication modules, and more.
