HDR-100-24

Code:A8046

Manufacturer: MEANWELL

The product comes directly from the manufacturer

Manufacturer's designation:HDR-100-24

Designation Minyx:HDR-100-24

MINYX stock 85 pcs EXTERNAL stock 8 632 pcs

Standard delivery time in weeks: 2

€22.11 /pcs with VAT

€18.27 /pcs without VAT

Quantity (Multiplicity: 1)

Minimum order units: 1 pcs

Product specifications

Description

AC/DC power supply in plastic box for DIN rail

Model series

HDR-100

Series

HDR

AC input voltage

85~264 V

DC input voltage

120~370 V

Input frequency

47~63 Hz

Power of convertor

92 W

Output voltage DC

24 V

Output current

3,83 A

Number of outputs

Isolation

4000 V

Efficiency (typ.)

90 %

Dimensions

70x90x54,5 mm

Operating temperature

-30~70 °C

Weight

270 g

Packaging and legislation

Type of packaging

Box

Packaging quantity small

Usual country of origin

Taiwan

Customs nomenclature

8504 40 95

MEAN WELL HDR-100-24 – Reliable DIN Rail Power Supply

The MEAN WELL HDR-100-24 is a compact switched-mode power supply with 92W output power and 24V DC (3.83A) output voltage, designed for industrial and automation applications. With high efficiency up to 90%, a wide input range of 85–264V AC / 120–370V DC, and protection against short circuits, overloads, and overvoltage, it ensures stable and safe power delivery even in demanding environments.

Key Features:

Input: 85–264V AC / 120–370V DC
Output: 24V DC / 3.83A / 92W
Efficiency up to 90%
Compact design for DIN rail TS-35 mounting (width: 70mm)
Protections: Short circuit, overvoltage, and overload
Certifications: IEC/EN 62368-1, UL 508, EAC
Operating temperature: -30°C to +70°C

Applications:
Ideal for industrial control systems, PLCs, sensors, security technologies, LED lighting, home automation, distribution panels, and IoT applications.
